JADIS  JPS3                                                                           Listino  ufficiale  .  14.450,00

Preamplificatore Phono con alimentazione separata. Questo Jadis include un preamplificatore phono MM e MC che utilizza tre ECC83 per MM e 2 6DJ8 per la fase di MC. Quanto al JPS2, la sua alimentazione specifica ricrea una tensione per il modulo con una frequenza di 80 Hz per evitare problemi che possono verificarsi a causa della frequenza 50 o 60 Hz dalla rete. L'alta tensione regolata da due tubi: 1 x EF86 e 1 x EL84. La regolazione della alta tensione assicurata da due tubi: 1 X EF86 e 1 x EL84. connettori dorati e ulteriori collegamenti sono in rame e argento che assicurano la trasmissione fedele dei segnali sonori. Il "punto per punto" convenzionale cablaggio d l'aerazione e la dimensione della scena sonora. La scelta dei componenti elettronici e il metodo di fabbricazione d la firma JADIS a questo dispositivo.Ingressi:1 mc/1mm- Telai :2 Valvole :2 x ECC88 3 x ECC83 1 x EF86 1 x EL84 - Misure:430 x 345 x 175 mm  ogni telaio- Peso:30kg - Consumo :65w

The JPS3 is Jadis' top phono stage. It will let you feel the music in your vinyl. Built with all point-to-point wiring, choice electrical components, gold plated connectors and high quality wiring throughout, the JPS3 offers you a state-of-the-art phono preamplifier with performance second to none.The JPS3 features a high voltage power supply running at 80Hz which provides superior low noise operation compared to typical power supplies running at 50Hz or 60Hz.Phono preamplifier with separated power supply. This Jadis includes an MM and MC phono preamplifier that uses three ECC83 for MM and 2 6DJ8 for the MC stage.As for the JPS2, its specific power supply recreates a voltage fo the module with a 80 Hz frequency in order to avoid problemsthat may occur due to the 50 or 60 Hz frequency from the main supply. The high voltage is regulated by two tubes: 1 x EF86 and 1 x EL84.The Jadis JPS3 is the phono preamplifier that will let you touch the full capability of the vinyl discs and give you the best of this analog source. Every single subtlety from the grooves will be perfectly transcripted for a greater listening pleasure. Type MM/MC with separated power supply Gain 57dB(MM)/84dB(MC) Input type 1 MM / 1 MCBandwidth RIAA Number of block 2 Tubes 2 x ECC88, 3 x ECC83, 1 x EF86, 1 x EL84 Dimensions 43 x 34.5 x 17.5 cm each Poids 30Kg Consommation 60W

References

The Jadis JPS3 is the phono preamplifier that will let you touch the full capability of the vinyl discs and give you the best of this analog source. Every single subtlety from the grooves will be perfectly transcripted for an increasing listening pleasure.


Specifications

Type RIAA phono preamplifier MM/MC with separated power supply
Gain 57dB Phono MM and 60 dB Phono MC
Input type one MM and one MC input
Bandwidth RIAA
Number of blocks 2, separate power supply
Tubes list 2 x ECC88 3 x ECC83 1 x EF86 1 x EL84
Dimensions 430 x 345 x 175 mm each
Weight 30Kg
Consumption 65W
