JADIS  DPMCMKII                                                                              Listino  ufficiale  €.  5.750,00

Il DPMC è un preamplificatore phono MM / MC con un controllo di livello. Esso utilizza 4 ECC83 per il preamplificatore e per la correzione RIAA. La  valvola  di alimentazione regolata garantisce la stabilità di questa unità. La versione MkII dispone di un nuovo layout interno per migliorare  isolamento e consente  di  regolare anche l'impedenza di ingresso di essere commutato tra 48KΩ, 1k, 300Ω, 100Ω per una migliore corrispondenza con la cartuccia. Questa unità è ideale per equipaggiare un amplificatore integrato con uno stadio phono state-of-the-art che vi permetterà di riscoprire la vostra collezione di dischi.Ingressi:1 mc/mm- Telai :1 - Valvole :ECC83 X 4 EL84 X 1 EF86 X1 - Misure:455x 320 x 125 mm  ogni telaio- Peso:11kg - Consumo :30 w

The DPMC is Jadis' entry level MM/MC phono amplifier. It is hand-crafted with point-to-point wiring, has 66dB of gain and a volume control that allows you to match the amp to an infinite variety of cartridges. The DPMC's key feature is a tube-based series pass regulator consisting of an EL84 beam power tube and an EF86 pentode. The tube regulated power supply ensures stability and the ultra-silent circuit lets the music shine through in its purist form. Four ECC83s are used for the preamp and RIAA correction.The DPMC is an MM/MC phono preamplifier with a level control. It uses 4 ECC83 for the preamp and for the RIAA correction. Tube regulated power supply ensures stability of thisunit. The MkII version feature a new internal layout for better solation and also allows the input impedance to be switched between 48KΩ, 1KΩ, 300Ω, 100Ω for a better match with yourcartridge. This unit is ideal to equip an integrated amplifier with a stateoftheart phono stage that will allow you to rediscoveryour records collection.The DPMC delivered plenty of virtues [...]. The DPMC soundedreally seductive. Think enhanced spatial perspective, and fatter,richer, and more liquid textures. The Jadis DPMC's tube signature us unmistakable. It romances the soul, and I for one could not resist its siren call. Type Phono MM/MC Gain 66 dB Input 1 MC/MM : 48KΩ, 1KΩ, 300Ω, 100Ω Output From 0 to 5V variable output Number of block 1 Tubes 4 x ECC83, 1 x EL84, 1 x EF86 Dimensions 45.5x32x12.5 cm Consumption 30W Weight 11 kg


References

The all-tubed units looked and felt sumptuous, with sound to match. The line-stage was ultrasilent with its simple and elegant circuitry. [...] What it added was more than pleasant, and didn't mask vital musical information.

Stereophile

The soundstage was spacious and superbly solid, as if carved from stone. Image specificity was first class. Tonal colors were vivid and midrange harmonic textures flowed sweetly with exceedingly low levels of grain. There was plenty of transient speed in evidence with sufficient lucidity to allow retrieval of low-level detail.When I think of an overly tubey, thick, and syrupy sound, I am reminded of the classic Dynaco PAS-2, the DPMC is light years removed from all that. Imagine tube sound without excessive fat - with the DPMC you can have your sonic cake and eat it too.It was able to communicate the music’s pace and rhythmic drive to a degree that is exceptional at this price point. The DPMC’s tube signature is unmistakable. It romances the soul, and I for one could not resist its siren call. With a good mm cartridge in tow, the DPMC is musically compelling. As the DPMC amply demonstrates, there is plenty of magic left in the classical approach, especially when coupled with a modern, well-regulated power supply. Join the fun, you’ll be glad you did.

Dick Olsher, The Absolute Sound



Specifications

Type phono MM/MC
Gain 66 dB
Input type 1 MC/MM input (48KΩ, 1KΩ, 300Ω, 100Ω)
Bandwidth RIAA
Number of blocks 1 chassis
Tubes list ECC83 X 4 EL84 X 1 EF86 X1
Dimensions 455 x 320 x 125 mm
Weight 11 Kg
Consumption 30 W
